Preview Release of Multi Channel Suite Software

Advantages of the Multi Channel Suite over MC_Rack

Experimenter

  • Every connected hardware is visible in the panel and switching is quick and easy
  • Experimental set-up is more flexible and more intuitive than with MC_Rack
  • A docking/tab-window concept facilitates a more flexible layout of the single instruments
  • Recording can be switched on and off independent of the data acquisition
  • MEA2100-System: 24bit resolution of the hardware is finally supported
  • MEA2100-System: Stimulation patterns can be designed from within the same software
  • MEA2100-System: Multiwell-MEAs are supported more intuitively



Analyzer

  • Arbitrary navigation through raw data is possible
  • New mode “Explore” for interactive setting of analysis parameters



DataManager

  • Exports files to HDF5 format for easy import in Matlab or Python



Please note that although we have tested the software, it is still no official release. Multi Channel Systems can not be held responsible if the software crashes or your experiment fails.

Instruments

We want to point out that this is a very first version, so the number of instruments is still very limited.

Experimenter

  • Continuous recording
  • Stimulator
  • Filter
  • Digital Event Detector
  • Spike Detector
  • Sweeps (shows the signals for a specified time frame around an event)



Analyzer

  • Show recorded data and filter them
  • No file can be saved



DataManager

  • Convert Experimenter files to HDF5 files for analysis in e.g. Matlab or Python

Download

Program files:

Complete Multi Channel Suite: Multi Channel Suite_0.9.9.5.zip
Experimenter (Full version includes .NET 4.5): Multi Channel Experimenter_0.9.9.5.exe, Multi Channel Experimenter_0.9.9.5_Full.exe
Analyzer (Full version includes .NET 4.5): Multi Channel Analyzer_0.9.9.5.exe, Multi Channel Analyzer_0.9.9.5_Full.exe
DataManager (Full version includes .NET 4.5): Multi Channel DataManager_1.0.0.exe, Multi Channel DataManager_1.0.0_Full.exe

Tools:

Wrapper Matlab: McsMatlabDataTools.zip
Wrapper Python: McsPyDataTools.zip

Documentation:

Quick Manual: MultiChannelSuite_QM_V0.9.9.5.pdf

Feedback

We would very much appreciate your feedback to our new software. As it is still in its early phase, your ideas are very valuable to us and we are happy to integrate as many of them as soon as we can. Please reply to support [at] multichannelsystems.com to share your thoughts or just give us a call at +49 7121 909 2525.



Thank you very much for your support and feedback. We hope that you like the Multi Channel Suite and it helps you advancing your research.

Your MCS-team
